Voltage Input |
AC 90-240V 47-63Hz, PF>0.9 |
Voltage Output |
24V, SMPS longevity 15000 hrs |
Rated Power |
90W(@220V 50Hz) |
Luminaire Efficiency |
>0.9, luminous efficacy >660 lm/W |
LED Lumens |
36pcs*3W Helio UV LED, total 27W radiometric power, about 11 lumens |
LED Wavelength |
380-405 nm |
Field Angle(10%) |
Standard 30 °, 8°, 15°, 45°, 60°, 60*1° |
PWM Frequency |
>1500Hz, video flicker free |
Control Signal |
DMX512, 32 bit Dim 4 square law dimming, smooth in low DMX value dimming, not jumping, no vision shock |
Control Mode |
DMX1990/DMX512A/stand alone/master and slave mode |
Chanel Option |
3CH, dimmer, strobe and dimming curve |
Housing Material |
Die cast aluminum ADC12, standard matte black, could be customized for glossy white painting |
Safety |
Appliance Class II, 3C 2.5mm2 VDE cable, flammability rating UL 94 V-1, IP65 rated |
Operate Temperature |
-20~+45℃, light board peak temperature 80℃ |
Certificate |
CE, Rohs, CQC, UL |
Weight |
4.7Kg, with two yokes 3mm thick supporting bracket |
Size |
30*32*39 CM |
