Brief description：
1. 4 PCS 15W Ostar FULL RGBW LED bulbs
2. 1920 lumens output
3. Field angle (10% intensity) 19 degree standard, even color mixing
4. Square appearance
5， led beam wash, narrow beam 8 degree
Size: 219*137*212 mm
Weight: 2.6KG
| Input Voltage | AC 100-240VAC, 47-63 Hz |
| Output Voltage | 24V DC, power factor>0.7 |
| Rated Power | 50W, typical consumption 44.6W/220V |
| Light Source | 4 PCS 15W Ostar FULL RGBW LED. Drive current for each chip 1A, total light output 1920 lumens, luminaire efficiency 43lm/W |
| Peak Intensity | 35505 Cd (10%field angle 19 Degree) |
| LED Color | R=625nm, G=525nm, B=465nm, White=6000K |
| Color Rendering Index(CRI) | Pure White Ra>90, R9>50 |
| Color Mixing Index | Standard deviation of chromaticity SDC<0.005 |
| Control Signal | Meet E1.11 - 2004 USITT DMX512-A standard, 32 bit precise dimming, smooth in low DMX value dimming, no vision shock |
| Channels | 3CH, 4CH, 5CH, 8CH, 9CH |
| Display | Touch operation, LED display show DMX signal status and turn off when no operation |
| Dimming | with Dim0-Dim4, 5 dimming curves, smooth dimming |
| PWM Frequency | >1.5KHz, flash rate endurance full Load>12Hz, full load/void load flash |
| Beam Angles | 9°, 15°, 18°, 45*15°, etc |
| Housing Material | Die cast aluminum, protection rate IP66 |
| Cooling Method | Natural cooling |
| Thermal Protection | NTC overheat protection |
| Connectors and Cables | IP67 Male/Female connectors |
| Accessories | Barn door, Hook, safety cable, signal extension cable, power extension cable |
| Housing Color | Standard matte black, could customized with pumpkin color. |
| Soldering Technology | 180℃ reflow soldering, 15000 hours life for SMPS and main board |
| Size | 219*137*212 mm |
| Net Weight | 2.6 Kg |
| Operating Temperature | -20℃ - +55℃ |
| Certificates | CE, Rohs |
