Features:
8760Lumens Output, could replace 400 watt traditional Halogen.No need to change original primary dimmer rack, no need to add extra DMX system,suits for applications as stage, studio room, save wire and labour cost.
F300UDMX is DMX dimming，for new project,1 to 1 changing Halogen 400, no need adding DMX signal, compatible to be dimming with halogen
Structure: New die cast model, similar size as traditional Par64, more stronger, good for rental application;
Patent new lamp body is designed to support heat sink, with better ventilation, no fans cooling, no noise! Suitable for strict control noise studio room.
Finished:Matte Balck, Could customize Matte white housing, Barndoor and color filter gel available.
Optic Design: Standard 3200K white light output, standard white, nature white, warm white, blue, etc, different colors to customize;
Field angle (10% intensity) 30 degree standard, 45 degree, 60-1 degree Optional.
Wattage: 130 Watt max consumed, power factor 90%;
More than 15000 Hours Longevity for SMPS and Main board.
Specifications:
| Voltage input |
DMX version AC 90-240V 47-63Hz |
| Max power consumption |
130W |
| PF |
0.9 |
| Light source |
36pcs*5W Cree XPG White color,28000K-8000K optional, standard 3200K, each BIN 150K, neutral White 4500K, each BIN 200K, 8760Lumens output |
| Dimming |
F300UDMX for DMX Dimming, 9 Channel，with Dim0-Dim4 5 dimming curve More than 15000 Hours Longevity for SMPS |
| Life span |
50 000 -100 000 hours |
| Beam Angle |
15°、25°、45°、60°、60*1°optional |
| PWM Frequency |
>7.8KHz, flicker free |
| Cooling method |
Natural cooling |
| Net Weight |
4.7Kg |
| Size |
30x32x39CM |
| IP Rate |
IP 20 |
| Cerficated |
UL CE, Rohs |
