virtuoso mp10

Light Source:
Red: 638nm / 3W；Green: 520nm / 3W；Blue: 445nm / 4W
Scanning Speed: 20Kpps
Input Voltage: AC 90–245V, 50–60Hz；Total Power: 725W

Laser Beam Parameters: Beam diameter at aperture < 3 mm, divergence angle < 1.5 mrad
Laser Safety: Overload Protection
Laser Source Lifespan: Over 20, 000 hours
Scanning Speed: 20Kpps
Scanning Angle: 60°

DMX Channels: 27 Channels
Dimming: 0–100% linear dimming
Control Modes: DMX / ILDA PC Control / Automatic
Basic Patterns: 200 pcs (3000 extended patterns, 255 animations)
Horizontal Rotation: Stepless Rotation (optional angles: 540°, 630°, 900°, 1800°, etc.)
Vertical Rotation: Stepless Rotation (optional angles: 270°, 180°, 540°, 1080°, etc.)

Ingress Protection Rating: IP65
Fanless design with heat dissipation through aluminum housing; equipped with new-type light source driver for low heat generation.
Applications: Cultural tourism landscape projects, outdoor landmark lighting, water screen & moving screen projection, large-scale performances
