Brief description：
1.4PCS 20W RGBW 4in1 / 6 in 1LED
2.Easy install and uninstall Light accesories
3.Mini size lampbody, easy install especially to be inside truss
Size and Weight: 119*123.5*123.5mm/ 1.95KG
| Model | Vibes Quad60-RGBL | Vibes Quad60-RGBALC |
| Input voltage | AC 100V-240V/50-60HZ | AC 100V-240V/50-60HZ |
| Power consumption | 80W | 65W |
| Lamp Type | 20W LED 4-in-1 R, G, B, L(4PCS) | 20W LED 6-in-1 R, G, B, A, L(Lemon), C(Cyan)(4PCS) |
| Life span | 50000~100000hours | 50000~100000hours |
| PWM Dimmer | 4300HZ(16666 grades) | 4300HZ(16666 grades) |
| Control Signal | DMX512 | DMX512 |
| Angle | 15°, 25°, 45° Optional | 15°, 25°, 45° Optional |
| Control mode | stand alone/ Master/Slaver | stand alone/ Master/Slaver |
| Channel | 10CH、6CH、4CH | 12CH、8CH、6CH |
| Function Effect | dimmer, strobe, gradual change, rainbow, self program running | dimmer, strobe, gradual change, rainbow, self program running |
| Built-in temperature control measurement function, when LED work overheated, intelligent reduce LED output power, current power output and temperature can be viewed. |
||
| Cooling mode | Fan Cooling | Fan Cooling |
| Anti-electricity intension | 1.5KV | 1.5KV |
| Insulation Resistance | >2MΩ | >2MΩ |
| Protection | IP20 | IP20 |
| Size | 119*123.5*123.5mm | 119*123.5*123.5mm |
| Net weight | 1.95 Kg | 1.95 Kg |
