Voltage : AC110-240V 50/60Hz
Max Power: 500 W
Source: 12pcs 40W RGBW 4in1 led
Beam degree: 1:7 zoom range from 5°-35
Tilt: 220 degree+ fine
LED Lifetime: Average 50, 000 hours
Led: pixel control
Strobe: 25 times per second
Dimmer:0-100% linear dimmer
Channel: 14/20/57 three channel mode
Control mode: DMX-512, Auto-run, Sound activated Cooling system: fan forced cooling system Working environment: indoor
Net weight: 14.8 KG
Fixture size: 102*10.75*27.7 cm
Package size: 110*19*37cm
Gross weight: 17 KG
Features:
1.Zoom Effect: Offers a versatile zoom effect with adjustable beam angles (5°-35°), providing flexibility for various lighting scenarios. Longman’s proprietary optical design ensures optimal light distribution and quality.
2.Pixel Precision: Equipped with 12x40W RGBW 4-in-1 LEDs, providing high-intensity light output with pixel-level control for intricate visual effects.
3.Moving Head Beam: Incorporates a moving head design for precise beam positioning, allowing for dynamic and flexible light placement. This stage lighting provides
4.Back Blinder Functionality: Features a dedicated back blinder light, adding depth and dimension to stage equipment productions.
5.Matrix Lighting: Designed for creating captivating LED matrix effects, enhancing the visual spectacle of performances.
6.RGBW 4in1 LED Linear Wash: Delivers a broad spectrum of colors with the efficiency of RGBW 4-in-1 LEDs, perfect for seamless linear washes.
7.Flower effect technology : Multi-RGBW-Coloured Flower Effect creates sharp, multi-colored spikes of light, fully rotatable for dynamic visual effects.
Introduction
The Moving Head LED Pixel Bar Light Phoenix 1240 is a cutting-edge luminaire designed for dynamic and versatile professional lighting applications in the entertainment industry. Combining powerful features, it offers a new dimension to stage lighting.
The Moving Head LED Pixel Bar Light finds applications in:
Live Performances: Ideal for concerts, theaters, and live events where dynamic entertainment lighting is essential.
Nightclubs and Bars: Enhances the atmosphere with vibrant colors, beam effects, and pixel-controlled displays.
Indoor Architectural Lighting: Perfect for creating eye-catching matrix lighting setups in architectural designs.
Summary
In summary, the Moving Head LED Pixel Bar Light redefines stage lighting with its pixel precision, zoom effect, moving head capabilities, back blinder functionality, and versatile applications. It introduces a new era of dynamic and customizable stage lighting experiences for entertainment and architectural settings.
Introduction:
Evolute Q1240 Zoom – Advanced Moving Head Pixel Bar Light for Stage & Visual Shows
The Evolute Q1240 Zoom by Longman represents a new generation of moving head pixel bar lights, engineered for dynamic stage effects, high-resolution pixel mapping, and immersive in-air visuals. Designed with precision and powered by cutting-edge LED technology, this linear bar fixture is ideal for both indoor and outdoor entertainment productions, including concerts, light shows, and multimedia performances.
High-Precision Pixel Control and Zoom Flexibility
At the core of the Evolute Q1240 Zoom is a powerful system of twelve independently controllable 40W RGBW LED modules, each producing an ultra-narrow 5° beam. These pixel engines form a bright, cohesive sheet of light that can be manipulated for a wide range of visual applications—from crisp beam chases to smooth wash effects.
Its 7:1 motorized zoom range (5°–35°) offers extreme flexibility, transforming narrow beams into wide spreads for wall grazing, footlights, or ambient washes. This makes it a versatile zoom linear bar light capable of adapting to the demands of live stages, architectural installs, or creative pixel layouts.
Unique Flower Effect and Creative Light Shaping
One of the standout features is Longman’s exclusive LMLED™ Multi-Coloured Flower Effect, projecting charismatic, flowing in-air animations that elevate the lighting design far beyond conventional pixel bars. This built-in optical animation system introduces dynamic texture and movement to any show environment.
In wash mode, the fixture also offers beam edge softening, enabling smooth, even blends that eliminate harsh transitions on surfaces or subjects.
Pixel Mapping Mastery with Advanced Control
Designed for professional pixel mapping applications, the Q1240 Zoom includes individual control over each LED cell, allowing custom color, intensity, and strobe manipulation per pixel. The result is high-impact visuals that synchronize effortlessly with music, video, or programmed scenes.
The fixture features:
Advanced Layers Management for multi-layered effect programming
Electronic strobe and stop effects
White CT emulation from 2500K to 8000K
Five selectable dimming curves for smooth fades
220° tilt range for wide motion sweeps
4 control modes including DMX and auto-run
Longman’s proprietary LM3™ low light linearity dimming ensures a smooth fade-to-black performance, critical for theatrical or cinematic applications.
Seamless Integration and Intelligent Design
The Evolute Q1240 Zoom is built with intelligent physical connectivity in mind. Fixtures can be arranged in linear lines or matrix grids without interrupting the uniform spacing of LED cells. This allows for consistent engine alignment both horizontally and vertically—ideal for scalable visual displays and architectural lighting.
Its auto-retreat / reposition function in the absence of DMX signal ensures consistent fixture orientation and simplifies setup during installations or mobile events.
Professional Performance in a Compact Frame
Whether you're designing high-energy lighting for a live concert, creating immersive backdrops for theater productions, or building a futuristic pixel-mapped light wall, the Evolute Q1240 Zoom delivers. With its stage pixel mapping effect light capabilities and smooth zoom performance, it is one of the most adaptable tools for lighting designers.
Key Features Overview
12 x 40W RGBW LEDs with individual pixel control
Motorized zoom: 5° – 35°
Flower animation effect with LMLED™ system
2500K–8000K white color temperature emulation
5 dimming curves + electronic strobe
Beam edge softening in wash mode
220° tilt range with fast sweeping motion
Seamless matrix or linear configuration
4 operating modes: DMX, auto, master/slave, sound-activated
Compact, lightweight, and tour-ready
Longman’s Evolute Q1240 Zoom is more than a light bar—it’s a programmable canvas for creative lighting. As a moving head linear bar light built with precision optics and powerful control features, it sets a new standard for lighting innovation.
