virtuoso Ap40







Input Voltage: AC 100~240V / 50~60Hz
Rated Power: 400W
Fuse: 10A
Red: 638nm / 12W
Green: 520nm / 12W
Blue: 445nm / 16W
Scanning Speed: 50Kpps
Model, Laser Color, Wavelength / Power
RGB 50W
Red: 638nm / 10W + Green: 520nm / 20W + Blue: 445nm / 20W (Brightness Adjustable)
Output Colors
True Color, Red, Green, Blue, Yellow, Cyan, Purple, White
Scanner
Galvo Speed: 40Kpps
Scanning Angle: 60°
Working Modes
ILDA, LAN, Pangolin FB4
Ingress Protection Rating: IP65
Fixture Dimensions: L 51 × W 52 × H 35 cm
Net Weight: 32 kg
Flight Case Dimensions: L 57 × W 46 × H 55 cm
Gross Weight: 52 kg

Shipping list includes the following items (Note: flight cases extra).
La lista de envío incluye los siguientes artículos (Nota: flight cases no incluidos,  costo adicional).
A lista de embarque inclui os seguintes itens (Obs.: flight cases cobrados à parte).
