Brief description：
1. 3PCS 14W Full RGBAWUV LED bulbs
2. 1220 lumens output
3. New appearance design patent, design idea is from Bowerbird
4. Wireless DMX solution and full chromaticity
Size: 103*181*207mm
Weight: 1KG, with 2mm thick double bracket
| Voltage Input | AC220V 47-63Hz, PF>0.95, could be customized for DC24V |
| Rated Power | 40W (32W 220V full load) |
| Luminaire Efficiency | 41lm/W, 3PCS 14W Full RGBAWUV 500mA current, 1220 lumens |
| LED Color | R=625nm, G=525nm, B=460nm, A=590nm, W=6500K, UV=390nm，offer multi-Color mixing，SDC<0.005 |
| Field Angle(10%) | standard 51°(4280 Cd on axis with LMTXL43HY), optional 37° |
| Control Signal | Meet E1.11 - 2004 USITT DMX512-A standard, able for PWM dimming constant voltage input |
| DMX Channels | LM-DMXA0 2.4GHz wireless, compatible with PAD PEN, 6CH, 7CH, 8CH, 10CH, 11CH |
| Dimming Curve | 32 bit linear dimming, PWM>600Hz, flicker free |
| Housing Material | ADC12 die cast aluminum, matte black, support other colors and barn door |
| Safety | Appliance Class II, 3*1 mm VDE cable for electric power input, shielded cable for signal, both are daisy chain, flammability rating UL 94 V-1, IP code is IP65 |
| Operate Temperature | -20~+45℃, board peak temperature 30℃ |
| Certificates | Product passes CE, RoHS |
| Weight | 1KG, with 2mm thick double bracket |
| Size | 103*181*207 mm |
