Brief description：
1. 7 PCS 10W 4-in-1 FULL RGBW LED
2. 2092 lumens output
3. Field angle (10% intensity) 33 degree standard, even color mixing
4. Mini square looking, with barn doors
Size:165*145*184 mm
Weight: 2.2KG
| Input Voltage | AC 100-240VAC, 47-63 Hz |
| Output Voltage | 28V DC, Power Factor>0.7 |
| Rated Power | 60W, typical consumption 48W/220V |
| Light Sources | 7 PCS 10W 4-in-1 FULL RGBW LED. Drive current for each chip 450mA total light output 2092 lumens, luminaire efficiency 39.7 lm/W |
| Peak Intensity | 11088C(10% field angle 33 Degree) |
| LED Color | R=625nm, G=525nm, B=465nm, A=590nm, White=6000K |
| Color Rendering | Pure White Ra>90, R9>50 |
| Color Mixing | Standard deviation of chromaticity SDC<0.005 |
| Control Signal | Meet E1.11 - 2004 USITT DMX512-A standard, 32 bit precise dimming, smooth in low DMX value dimming, no vision shock |
| Channels | 3CH, 4CH, 5CH, 8CH, 9CH |
| Display | Touch screen operation, LED display show DMX status and turn off by self when no operations |
| Dimming | with Dim0-Dim4, 5 dimming curve, smooth dimming |
| PWM frequency | >1.5KHz, flash rate endurance full load>12Hz, full load/void load flash |
| Beam Angles | 8°, 15°, 18°, 45*15°, etc. |
| Housing Material | Die cast aluminum, protection rate IP66 |
| Cooling Method | Natural cooling |
| Thermal Protection | NTC thermistor overheat protection |
| Connectors and Cables | IP67 male / female connectors |
| Accessories | Barn door, hook, safety cable, signal extension cable, power extension cable |
| Housing Color | Standard matte black, could customized pumpkin color |
| Soldering Technology | 180℃ reflow soldering, at least 15000 hours longevity for SMPS and main board |
| Size | 165*145*184 mm |
| Net Weight | 2.2 Kg |
| Operating Temperature | -20℃ - +55℃ |
| Certificate | CE, Rohs |
