SOURCE
● Light Source Type: DLP TI 0.45" DMD
● Rated Lifetime: 20000hours
● Output Luminous Flux（lm）: 1000 ANSI lumens
● Contrast Ratio: 500:1
● Lens Throw Ratio: 1.2
● Aspect Ratio: 16:9
● Resolution: 1280 x800P, support 1080P
POWER
● Input Voltage: 100-240V AC, 50/60Hz
● Maximum Power: 110W
FUNCTION MODULE
● DLP\DMD Projection Optomechanical Driver: control and drive the Optomechanical projection display
● Whole DLP\DMD Projection Optomechanical Lens: Optomechanical lens combination
● Interactive Capture Device: Infrared capture camera
● Infrared remote control
● USB transfer
● Ethernet network connection
● Support WIFI, Bluetooth connection
● Built-in speaker
MAIN FEATURES
● Keystone Correction: Horizontal/vertical +/-40°
● Focuse: Electric focus
● Can realize interactive projection and fusion
CONTENT MANAGEMENT
● Memory card can be added if user needs
● Built-in system board Android board stores images and videos
● Internal Storage: High speed internal memory for user content–32 GB
● Remote content management
CONNECTIONS
● Power In/Out Connector: 3-pin waterproof power cord
● USB Interface : 1 USB interface, input/output picture and video
● LAN port in/out: Network remote transmission
Ethernet port in/out: RJ45
PHYSICAL
● Body Material: Die cast aluminum
● Body Color: Grey
● Proteciton Rate: IP65
● Installation: Ceiling, Wall, Ground
● Working Temperature: -25—40 ℃
Weight&Dimension
● Net Wight: 8.75kg
● Dimenison: 190x 331x 448mm
